Topcon ES-55 Reflectorless Total Station
| Stok | Tersedia |
| Kategori | Total Station |
Topcon ES-55 Reflectorless Total Station
Total Station Topcon ES-55 Reflectorless
Topcon Total Station dengan Akurasi 5-Detik
Total Station Topcon ES 55 merupakan Total Station Reflectorless dengan akurasi 5-detik dan kompensasi sumbu ganda memberikan solusi survei entry-level. Cepat dan sangat akurat, mengukur sudut dan jarak hingga 1.148 kaki dalam mode reflectorless dan 13.120 kaki saat menggunakan prisma tunggal. Ini juga memiliki balok EDM koaksial built-in dan laser pointer.
Menampilkan tampilan grafis tunggal dan 25 tombol alfanumerik, Topcon ES-55 menawarkan kontrol cepat dan mudah dan setup. total station ini mampu menyimpan 5.000 poin dalam memori internal dan menghubungkan dengan pengumpul data Topcon, seperti FC-5000, FC-236, FC-2600, Tesla dan lebih untuk transfer data mulus.
Total Station Topcon ES 55 dengan rating IP66, ES-55 adalah tahan debu dan tahan air. stasiun reflectorless Jumlah Topcon ini memiliki daya tahan baterai 15 jam, software survei on-penyair, dan dilengkapi dengan garansi distributor.
Features Total Station Topcon ES 55 Reflectorless
- 5-second accuracy
- Range of 1,148 feet
- 5,000-point internal memory
- Dual axis compensation
- Laser pointer and optical plummet
- Fast and powerful EDM
- Quick and easy trigger key
- Horizontal and vertical locking tangents
- On-board survey software
- RS232 serial port
- Dual graphic LCD
- 25-key keyboard, with 4-way directional backlit arrow key
- 15-hour battery life
- Water resistant and dustproof to IP-6
Specifications Total Station Topcon ES 55 Reflectorless
| General | |
| Weight | 12.3 lbs (5.6 kg) |
| Dimensions | 7.5 in x 6.8 in x 13.7 in (19.1 cm x 17.4 cm x 34.8 cm) |
| Warranty | 1-year |
| Protection Class | IP66 (dust proof and powerful water jets and heavy seas resistant) |
| Tripod Thread | 5/8 x 11 in. |
| Internal Memory | 5,000 points |
| Software | On-board |
| Guide Light | yes |
| Angle Measurement | |
| Accuracy | 5-second |
| Distance Measurement | |
| Unit of Measure (distance display) | m/ft/in. |
| EDM Accuracy (Precision) | ±(2mm + 2ppm x D) for prism; ±(3mm + 2ppm x D) for no prism |
| Minimum Reading | 350 m (1,148 ft) |
| Tilt Sensor/Compensator | |
| Range | ± 6 |
| Type | Dual axis liquid |
| Battery/Power | |
| Power Source | Rechargeable Li-ion battery |
| Battery Life | 15 hours |
| Battery Life Alert | yes |
| Voltage | 7.2v |
| Optical Plummet | |
| Magnification | 3x |
| Level | |
| Circular Bubble Vial | 10 minutes per division/(2 mm) |
| Telescope | |
| Length of Tube | 6.7 in (17.1 cm) |
| Image | Erect |
| Diameter of Objective Lens (Aperture) | 1.9 in (48mm) EDM |
| Magnification | 30x |
| Field of View | 1 degree 30 arcmin |
| Resolving Power | 2.5 arcsec |
| Minimum Focus Distance | 1.3 m (4.3 ft) |
| Reticle Illumination | 5 brightness levels |
| Reflectorless | yes |
| Display and Keypad | |
| Type | Graphic LCD |
| Sides | Single |
| Keys | Alphanumeric |
| Backlight | yes |
| Pixels | 192 x 80 |
| Temperature | |
| Operating | -4Fº~140ºF (-20ºC~60ºC) |
| Applications | |
| Surveying and Construction | yes |
| Mapping and GIS (geographic information systems) | yes |
| Utilities | yes |
| Environment Studies | yes |
| Geomarking | yes |
| Archaeology | yes |
| Accident Reconstruction | yes |
| Measurement Range (under fair weather conditions) | |
| Single Prism | 4,000 m (13,123 ft) |
| No Prism | 350 m (1,148 ft) |
| Mini Prism | 500 m (1,640 ft) |
| Reflector Sheet | 500 m (1,640 ft) |
| Functions | |
| Coordinate Measurement Point | yes |
| Angle and Distance Stake Out | yes |
| Stake Out Line | yes |
| Offsets | yes |
| Missing Line | yes |
| Remote Elevation | yes |
| Resection | yes |
| Area Calculation | yes |
| Measurement Time | |
| Fine | 0.9-second |
| Rapid | 0.7-second |
| Tracking | 0.3-second |
| Laser Pointer | |
| Class | Coaxial red laser using EDM beam |
| Interface | |
| Pin Port |
RS-232C |
